Use Puppeteer and Nodejs to take screenshots and PDFs — as a Service

Did you ever thought of a simple solution to create screenshots programmatically?

Photo by Bank Phrom on Unsplash

As a developer I wanted to create a simple service which creates dynamic websites and have them easily sharable via screenshots and PDF. I could have created a simple NodeJS application (like described in this article) just to solve the problem at a time but thought: “Why do I not make it a simple service?”.

The basics — a simple NodeJS application spawning a puppeteer controlled headless browser to capture screenshots and images from a website — where already in place, but now I wanted to make it a bit more versatile and consumable.

What is a bit more?

• A simple and straightforward API
• Param validation
• Documentation
• Testing
• Security considerations
• Docker Images
• Simple deployment to e.g. Heroku

The API

I decided to spawn up a simple NodeJS service with ExpressJS. It is very simple and consists of two endpoints: /api/shot and /api/pdf.

I used apidoc to create the documentation inline of my code, once I build the documentation it is available under /docs (preview).

//...
/**
 * @api {get} /pdf obtain a pdf of a page
 * @apiName TakeScreenshot
 * @apiGroup PDF
 * @apiVersion 1.0.0
 *
 * @apiParam {String} url a url to be looked up
 * @apiParam {Number} [w] width of the viewport
 * @apiParam {Number} [h] height of the viewport
 * @apiParam {String} [d] device to use for the viewport - overwrites other v/h parameters
 *
 * @apiSuccess {File} pdf the generated pdf
 * @apiError {Object} Errors returned errors
 */
//...

✓ Documentation

Beside the documentation, I decided to use ajv for param validation as it is blazing fast and well maintained. The schema live in schema.js and are very simple.

const { devices } = require('./util');

const screenshotSchema = {
  title: 'Page screenshot',
  description: 'Take screenshot of a page',
  type: 'object',
  properties: {
    url: {
      type: 'string',
      format: 'uri',
      pattern: '^(https?|http?)://',
      minLength: 1,
      maxLength: 255,
    },
    selector: {
      type: 'string',
      minLength: 1,
      maxLength: 255,
    },
  },
  required: ['url'],
};

const pdfSchema = {
  title: 'PDF page print',
  description: 'Take pdf of a page',
  type: 'object',
  properties: {
    url: {
      type: 'string',
      format: 'uri',
      pattern: '^(https?|http?)://',
      minLength: 1,
      maxLength: 255,
    },
    w: {
      type: 'integer',
      minimum: 1,
      maximum: 12288,
    },
    h: {
      type: 'integer',
      minimum: 1,
      maximum: 12288,
    },
    d: {
      type: 'string',
      enum: Object.keys(devices),
    },
  },
  required: ['url'],
};

module.exports = { screenshotSchema, pdfSchema };

Now, I just need to make sure I validate my request parameters with the schema for each endpoint.

//...
router.get('/shot', async (req, res) => {
  const validate = ajv.compile(screenshotSchema);
  const result = await validate(req.query);
  if (!result) {
    const errors = await parseAJVErrors(validate.errors);
    // return with the validation errors
    return res.status(400).json({ errors });
  }
  const { url, selector } = req.query;
//use the params now

✓ Param validation

And finally we want to have a simple API — just two endpoints replying to GET requests. One for screenshots available at /api/shot and the second for PDFs available at /api/pdf. As we work with GET requests, we only support query parameters.

✓ Simple API

Testing

It is a key differentiator to not only publish a project as open source and let it be there, but having also a set of tests that others can verify the functionality through running the tests.

I decided to try out ava with this project and I have to admit, that it offers a candid experience to the your main functionality.

const test = require('ava');
const { shot: screenshot, pdf } = require('./capture');
const fs = require('fs');

test('create screenshots', async (t) => {
  const screenshotBuffer = await screenshot({ url: 'https://www.google.com' });
  t.assert(
    screenshotBuffer.toString('binary').length > 1,
    'Should have generated a screenshot',
  );
});
test('create screenshot by selector', async (t) => {
  const screenshotSelectorBuffer = await screenshot({
    url: 'https://card-joy.web.app/v?img=c1&t=Merry%20Christmas!&p=topLeft',
    selector: '#root > div > div > div > img',
  });
  t.assert(
    screenshotSelectorBuffer.toString('binary').length > 1,
    'Should have generated a screenshot',
  );
});
test('create pdf', async (t) => {
  const generated = await pdf({ url: 'https://www.google.com' });
  t.assert(generated.length > 0, 'Should have generated a pdf');
});

And finally I set the test command in the package.json to “test”: “ava — verbose” — using verbose to get more information on each testcase.

✓ Testing

Security

As this is a service, which can easily pulled into an existing project as a single purpose microservice, I decided to use helmet to secure the Express App which sets various HTTP headers to mitigate common security pitfalls.

Last but not least, I added rate-limiting which defaults to 20 requests per 15 minutes per IP and is stored in memory.

✓ common security pitfalls covered

Deployment

The service can easily be run with docker. The image packages all dependencies including a chrome browser.

$ docker run -it --rm -p 3000:3000 chrkaatz/the-snap

Or if you already got a Heroku Account, you can use the Deploy to Heroku Button on the Project.

For the setup, I added app.json with the following contents to use Nodejs and a Buildpack enabling the use of puppeteer within Heroku.

{
    "name": "The Snap",
    "description": "A simple service to obtain screenshots and PDFs from pages",
    "repository": "https://github.com/chrkaatz/the-snap",
    "logo": "https://github.com/chrkaatz/the-snap/raw/main/logo.png",
    "keywords": ["node", "puppeteer", "screenshot", "api", "pdf"],
    "buildpacks": [
        {
            "url": "heroku/nodejs"
        },
        {
          "url": "https://buildpack-registry.s3.amazonaws.com/buildpacks/jontewks/puppeteer.tgz"
        }
    ],
    "env": {
        "HUSKY": {
            "description": "Disable git hooks managed by husky",
            "value": "0"
        }
    }
  }

✓ Deployment

Code

The source can be found at https://github.com/chrkaatz/the-snap and the working version checked out at https://the-snap.herokuapp.com/.

Final note: The Homepage is made with MVP.css and is super simple to use. It only took 5 minutes…
